NFPA
South West Research Institute (www.swri.edu)has tested the QUICK FIST clamps and all products meet the 9G Force standard when the weight of the item being held by the clamp does not exceed the following loads:
Non Crew Areas – Safe Working Load – in lbs (1lb=0.454kgs) | 1kg = 2.20 lbs | |||
Item # | Product | One Clamp | Two Clamps | |
30052 | Mini Quick Fist Clamp | 25 | 50 | |
10011 | Original Quick Fist Clamp | 25 | 50 | |
20022 | Super Quick Fist Clamp | 50 | 100 | |
40040 | Long-Arm Quick Fist Clamp | 50 | 100 | |
50052 | 3″ Nzzle Quick Fist Clamp | 50 | 100 | |
60022 | XL Quick Fist Clamp | 150 | 300 | |
80011 | Go-Between Quick Fist Clamp | 50 | 100 | |
Crew Areas – Maximum Weight – in lbs (1lb=0.454kgs) | 1kg = 2.20 lbs | |||
Item # | Product | One Clamp | Two Clamps | |
30052 | Mini Quick Fist Clamp | 5 | 10 | |
10011 | Original Quick Fist Clamp | 5 | 10 | |
20022 | Super Quick Fist Clamp | 15 | 30 | |
40040 | Long-Arm Quick Fist Clamp | 15 | 30 | |
50052 | 3″ Nzzle Quick Fist Clamp | 15 | 30 | |
60022 | XL Quick Fist Clamp | 50 | 100 | |
80011 | Go-Between Quick Fist Clamp | 15 | 30 |
